Garrett G42-1585 G-Series II 79mm Supercore (938339-5003S)
GRT938339-5003SThe G-Series II G42-1585 pairs a 79mm compressor inducer with a Garrett rating of 475 to 1585 HP on 2.0L to 7.0L engines.
It uses Gen I compressor and turbine housings, and Garrett's new compressor aero flows up to 10% more than Gen I at peak pressure ratio and peak turbo rpm. A calibration is required to turn that flow into horsepower. Gen I owners can also upgrade with just the CHRA (938338-5003S), per Garrett.
Specs
- Supercore PN: 938339-5003S (CHRA 938338-5003S)
- Horsepower rating: 475-1585, Garrett estimate
- Displacement: 2.0L-7.0L
- Compressor: 79mm inducer, 98mm exducer, 65 trim, 0.85 A/R
- Turbine: 82mm inducer, 75mm exducer, 84 trim
- Max turbo speed: 120,000 rpm (speed sensor sold separately)
- Included: water fittings
- Turbine housing: sold separately; uses G42 Gen I turbine housing kits
Available now at PPEI Tuning, shipping fast from our local and nationwide warehouses.
