Garrett Direct Fit Intercooler for 2015+ Ford F-150 and Raptor 3.5L / 2.7L EcoBoost (870702-6001)
GRT870702-6001Garrett's direct fit intercooler for the 2015+ F-150 and Raptor 3.5L and 2.7L EcoBoost has an 83% larger core than stock. It carries CARB EO D-794, which covers 2015-2016 F-150 2.7L and 2011-2016 F-150 3.5L.
Garrett estimates a 30% reduction in pressure drop, and its optimized end tanks improve flow through the core. It supports up to 750 horsepower and reuses the stock bolts, hoses and clamps. A fully machined drain plug, removed with a 3/8 open ended wrench, clears the condensation buildup common on the F-150. The active grille shutters must be removed to install it.
Specs
- Part number: 870702-6001
- Emissions: CARB EO D-794, which covers 2015-2016 F-150 2.7L and 2011-2016 F-150 3.5L
- Supports: up to 750 horsepower, per Garrett
- Size: 21 in x 5.32 in x 9.43 in
- Construction: vacuum brazed bar-and-plate, TIG welded, cast aluminum end tanks, advanced offset fin design
- Drain plug: fully machined, 3/8 open ended wrench
Vehicle fitment
Per Garrett for part 870702-6001: 2015+ Ford F-150 and Raptor with the 3.5L or 2.7L EcoBoost.
Available now at PPEI Tuning, shipping fast from our local and nationwide warehouses.
